Chapter 4

%% 4.4(b) 验证卷积定理

b1 = [7,6,5,4,-4,-5,-6,-7];

b2 = [2,2,-5,-5,6,6,-7,-7];

N1 = length(b1);

N2 = length(b2);

ans1 = conv(b1,b2);

t = fft([b1,zeros(1,N2-1)]).*fft([b2,zeros(1,N1-1)]);

ans2 = ifft(t);

disp(num2str(ans1-ans2));

% 经验算结果为0

%% 4.9 利用滤波器进行频域滤波

im = imread('twins.tif');

im = rgb2gray(im);

ff = fftshift(fft2(im));

figure(2)

subplot(2,4,1),imshow(im),title('原始图像');

subplot(2,4,2),imshow(mat2gray(log(abs(ff)))),title('频域图像');

[a,b] = size(im);

[x,y] = meshgrid(-b/2:b/2-1,-a/2:a/2 - 1);

z = sqrt(x.^2 + y.^2);

fil = (z15);

imf2 = ifft2(ff.*fih);

subplot(2,4,4),imshow(abs(imf2/256)),title('理想高通滤波');

fig = mat2gray(fspecial('gaussian', 256, 30));

imf3 = ifft2(ff.*fig);

subplot(2,4,7),imshow(abs(imf3/256)),title('高斯滤波');

d=15;n=2;

fibl = 1./(1+(sqrt(2)-1)*((x.^2+y.^2)/d^2).^n);

fibh = 1-fibl;

imf4 = ifft2(ff.*fibl);

imf5 = ifft2(ff.*fibh);

subplot(2,4,5),imshow(abs(imf4/256)),title('巴特沃斯低通');

subplot(2,4,6),imshow(abs(imf5/256)),title('巴特沃斯高通');

Chapter5

clc;

clear all;

f = imread('flowers.tif');

fg = rgb2gray(f);

f = im2uint8(f(30:285,60:315));

figure,imshow(f)

%?ó5%?·????éù

f_sp = imnoise(f,'salt & pepper',0.05);

figure,imshow(f_sp)

%average filtering

a3 = fspecial('average');

f_sp_a3 = filter2(a3,f_sp);

figure,imshow(f_sp_a3/256)

%median filtering

f_sp_m3 = medfilt2(f_sp);

figure,imshow(f_sp_m3)

%the outlier method

f_sp_out = outlier(f_sp,0.2);

figure,imshow(f_sp_out)

%pseudo_median filtering

for i = 1:256

for j = 1:256

if(i==1 || i==256 || j==1 || j==256 )

f_sp_psemed(i,j) = f_sp(i,j);

else

f_sp_psemed(i,j) = 0.5*max1(min1(f_sp(i,j-1),f_sp(i-1,j),f_sp(i,j)),min1(f_sp(i-1,j),f_sp(i,j),f_sp(i+1,j)),min1(f_sp(i,j),f_sp(i+1,j),f_sp(i,j+1))) + 0.5*min1(max1(f_sp(i,j-1),f_sp(i-1,j),f_sp(i,j)),max1(f_sp(i-1,j),f_sp(i,j),f_sp(i+1,j)),max1(f_sp(i,j),f_sp(i+1,j),f_sp(i,j+1)));

end

end

end

figure,imshow(f_sp_psemed)

function y = max1(a,b,c)

max=a;

if maxc

min=c;

end

y = min;

function res=outlier(im,d)

% OUTLIER(IMAGE,D) removes salt and pepper noise using an outlier method.

% This is done by using the following algorithm:

%% For each pixel in the image, if the difference between its grey value

% and the average of its eight neighbours is greater than D, it is

% classified as noisy, and its grey value is changed to that of the

% average of its neighbours.

%% IMAGE can be of type UINT8 or DOUBLE; the output is of type

% UINT8. The threshold value D must be chosen to be between 0 and 1.

f=[0.125 0.125 0.125; 0.125 0 0.125; 0.125 0.125 0.125];

imd=im2double(im);

imf=filter2(f,imd);

r=abs(imd-imf)-d>0;

res=im2uint8(r.*imf+(1-r).*imd);

chapter6

clc

clear all;

f = imread('cameraman.tif');

[x,y] = meshgrid(1:256,1:256);

%% (a)s=1+sin(x/3+y/5)

s1 = 1+sin(x/3+y/5);

ts1 = (double(f)/128+s1)/4;

fig 内容过长,仅展示头部和尾部部分文字预览,全文请查看图片预览。 ];

B3 = [1 0 0;

0 0 0;

0 0 1];

figure,imshow(A1)

figure,imshow(B1)

%erosion

ce = imerode(A1,B1);

figure,imshow(ce)

%dilation

cd = imdilate(A1,B1);

figure,imshow(cd)

% opening

ci = imopen(A1,B1);

figure,imshow(ci)

% closing

cc = imclose(A1,B1);

figure,imshow(cc)

[文章尾部最后300字内容到此结束,中间部分内容请查看底下的图片预览]请点击下方选择您需要的文档下载。
